Category:
Halyard and Sheet Lines
| Racing level
Application: Main Halyard, Genoa Halyard, Spinnaker/gennaker Halyard, Outhaul, Downhaul, Reefing Line 1, Reefing Line 2, Backstays
Construction: Double braided heat set line
Core: 100% Dyneema® SK 78, braided
Inner cover: Polyester staple (from dia 6 mm)
Outer cover: High Tenacity Polyester
D–RACE is line with high strength and extremely strong cover. Holds well in stoppers. Due to the sophisticated process of core heat setting and fibre stretching, the line feels stiff to the touch but during the first days of use gets required flexibility. Robust cover, long service life, holds in stoppers, works well in blocks.
| Diameter | Breaking load | Weight | |||
|---|---|---|---|---|---|
| mm | inch | daN | lbs | kg/100 m | lbs/100 feet |
| 3 | 1/8 | 400 | 880 | 0.7 | 0.8 |
| 4 | 5/32 | 750 | 1650 | 1.0 | 0.7 |
| 5 | 3/16 | 1300 | 2860 | 1.5 | 1.0 |
| 6 | 1/4 | 1800 | 3960 | 2.8 | 1.9 |
| 8 | 5/16 | 3300 | 7260 | 4.7 | 3.2 |
| 10 | 3/8 | 5550 | 12210 | 7.6 | 5.1 |
| 12 | 1/2 | 8200 | 18040 | 9.9 | 6.7 |
| 14 | 9/16 | 10200 | 22440 | 12.0 | 8.1 |
